PHOTON

Timeline: create Regions vimeo.comPlays from Vimeo, which receives your IP address once you press play. Privacy

OPEN THE TIMELINE MODULE

Select Show > Timeline OR press Alt + T.

Locate Regions Editing in the Timeline window and activate the Display toggle.
Click on the + button to create a new Region.
Set the Region In-point at 00:00:00:00.
Set the Region Out-point at 00:02:00:00.
Create a second Region on the Timeline.
Change the In-Point and Out-Point timing by selecting the Region and holding left + click

while moving it on the Timeline.
Select one of the Region’s edge to adjust its duration.

Cue Editor: Create Cues and Jump Between Regions vimeo.comPlays from Vimeo, which receives your IP address once you press play. Privacy

OPEN THE CUE EDITOR MODULE

Select Show > Cue Editor OR press Alt + Q.

Create a new cue. Click on the + button.
Activate the Record toggle.
Navigate back to the Timeline module. Select Show > Timeline OR press Alt + T
Select region 1.
Navigate back to the Cue Editor module. Select Show > Cue Editor OR press Alt + Q.
Deactivate the Record toggle to stop recording actions.
Repeat previous steps for region 2.
Click on the Go button to jump from the current Playhead position to region 1 or region 2.

Timeline: Use Cue Clips to Jump Between Regions vimeo.comPlays from Vimeo, which receives your IP address once you press play. Privacy

OPEN THE TIMELINE MODULE

Select Show > Timeline OR press Alt + T.
